24 ports, 24 PoE ports switch UTEPO UTP7524GE-PoE-4GF
- 24 x Gigabit uplink Ethernet ports
- 4 x Gigabit uplink optical fiber ports
- 24-PoE ports
- Watchdog
|
|
DPD Pick up terminal. Delivery within 1-8 days. ( from 3,00 €) |
|
|
Delivery via DPD courier service. Delivery within 1-8 days. ( from 4,00 €) |
Power Supply | Mains on load |
Voltage Range | AC 100～240V 50/60Hz Auto-sensing |
Power Consumption | 450W |
Ethernet Port | Copper ports: 10/ 100/ 1000Mbps adaptive Rj45 ports support IEEE 802.3 af/at SFP ports: 1000Base-X SFP port(Mini-GBIC) |
Transmission Distance | Copper ports: 100m SFP ports: depend on SFP module |
PoE Ports | Single port<30W,whole<390W |
Network Standard | IEEE802.3 、IEEE802.3u、IEEE802.3ab、IEEE802.3Z、 IEEE802.3X、 IEEE 802.1Q IEEE 802.1p IEEE 802.3ad、 IEEE 802.1D、IEEE 802.1X |
Switch Capacity | 56Gbps |
Packet Buffer | 12Mb |
Packet Forwarding Rate | 41.66Mpps |
MAC | 16K |
Management | Management L2 + PoE |
ESD | 6KV/8KV Per: IEC61000- 4- 2 |
Lightning Protection | 6KV Per: IEC61000-4-5 |
Operation Temperature | -10℃～55℃ |
Storage Temperature | -40℃～85℃ |
Humidity(non-condensing) | 0～95% |
Dimensions(LxWxH) | 442mm×320mm×44mm |
Material | Sheet Metal |
Color | Black |
Weight | 4. 35kg |
