24-port switch CUDY GS1024

  • Type: Switch
  • Model: CUDY GS1024
  • Ports: 24 x 100 Mbps
  • Switching Capacity: 10.8 Gbps
  • Forwarding Rate: 8 Mpps
  • MAC Address Table: 3K
  • Port Extension (Ports 9-24): >250 m @ 10 Mbps
  • Modes: VLAN / Default / Extend
  • PoE Standard: 802.3af/at
  • EDS Protection: 6 kV
  • Mounting: Rack
  • Operating Temperature: 0°C to 40°C
€67.99 (tax incl.) €67.99 (tax excl.)
check Turime sandėlyje

archive

 DPD Pick up terminal. Delivery within 1-8 days.  ( from 3,00 €)

local_shipping

 Delivery via DPD courier service. Delivery within 1-8 days.  ( from 4,00 €)

  • General
  • Model VersionGS1024 3.0
  • Gigabit RJ45 Ports24
  • Extend Mode Ports#1~#22
  • VLAN Mode Ports#1~#22
  • LED IndicatorsPower, Speed/Link/ACT of Each Ethernet Port
  • Power InputAC Inlet
  • Physical ButtonsVLAN/Default/Extend DIP Switch
  • Copper Speed and DistanceCat. 3+: 100m @ 10 Mbps, Cat. 5+: 100m @ 100 Mbps, Cat. 5e+: 100m @ Gigabit, 250m @ 10 Mbps (Extend Mode only)
  • Copper Speed Note250-meter transmission only available in Extend Mode
  • MAC Address Table8192
  • Max Switching Capacity48 Gbps
  • Max Forwarding Rate35.712 Mpps
  • Jumbo Frame15 KB
  • Packet Buffer4 Mbit
  • Basic Power SavingTrue
  • Power MethodsAC
  • AC Input Range90–260V~, 50/60Hz
  • Max Power Consumption11W
  • Idle Power Consumption6.8W
  • 802.3 Protocols802.3x Flow Control, 802.3i 10BASE-T, 802.3u 100BASE-TX, 802.3ab 1000BASE-T
  • 802.1 Protocols802.1p: LAN Layer 2 QoS/CoS
  • L2 FeaturesIGMP Snooping, Loop Prevention, Loop Detection, DSCP QoS, 802.1p QoS
  • Grounding MethodsThree-Prong Plug, Grounding Point
  • EMS ProtectionIEC/EN 61000-4-2 Level 3 ESD: Contact: 6kV; Air: 8kV, IEC/EN 61000-4-5 Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV
  • Operating Temperature0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
  • Storage Temperature-40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
  • Operating Humidity10% ~ 90% non-condensing
  • Storage Humidity5% ~ 90% non-condensing
  • Dimensions270×182×44 mm (10.63×7.17×1.73 inches)
  • Product Weight1059 g (37.36 oz.)
  • Casing MaterialMetal
  • Installation OptionsDesktop, Rackmount via Brackets
  • Package ContentGS1024, Power Cord, Installation Guide, Mounting Kit
