Dimmable LED switching power supply 200W 12V 16A IP67 Mean Well XLG-200-12-A
zoom_out_map
chevron_left chevron_right
New

Dimmable LED switching power supply 200W 12V 16A IP67 Mean Well XLG-200-12-A

  • Type: LED switching power supply
  • Model: XLG-200-12-A
  • Output voltage: 12 V
  • Power: 200 W
  • Current: 16 A
  • Protection rating: IP67
  • Brand: MEAN WELL
€51.80 (tax incl.) €51.80 (tax excl.)
check Turime sandėlyje

archive

 DPD Pick up terminal. Delivery within 1-8 days.  ( from 3,00 €)

local_shipping

 Delivery via DPD courier service. Delivery within 1-8 days.  ( from 4,00 €)

  • General
  • ModelXLG-200-12-A
  • DC Voltage12V
  • Rated Current16A
  • Current Adjustment Range8 ~ 16A (adjustable via built-in potentiometer)
  • Rated Power192W
  • Voltage Range8.4 ~ 12V
  • Constant Current Region13.5 ~ 18V
  • Ripple & Noise (max.)150mVp-p
  • Voltage Tolerance±3.0%
  • Line Regulation±0.5%
  • Load Regulation±2%
  • Efficiency (Typ.)92%
  • AC Input Range100 ~ 305VAC; 142 ~ 431VDC
  • AC Current (Typ.)2.2A / 115VAC; 1.1A / 230VAC; 0.9A / 277VAC
  • Inrush Current (Typ.)65A at 230VAC (cold start)
  • Power FactorPF ≥ 0.97 / 115VAC, PF ≥ 0.95 / 230VAC, PF ≥ 0.92 / 277VAC (at full load)
  • Total Harmonic Distortion (THD)<10% (@ load ≥ 50% for 115/230VAC; ≥ 75% for 277VAC)
  • Setup, Rise Time500ms, 100ms / 230VAC; 1200ms, 100ms / 115VAC
  • Hold Up Time10ms / 230VAC; 10ms / 115VAC
  • No Load Power Consumption< 0.5W
  • Over Voltage Protection13.5 ~ 18V, shut down output, re-power on to recover
  • Over Current Protection110 ~ 160%, hiccup mode, auto recovery
  • Short Circuit ProtectionHiccup mode, auto recovery
  • Over Temperature ProtectionShut down output, re-power on to recover
  • Working Temperature-40 ~ +80℃ (Tcase)
  • Max. Case Temperature90℃
  • Working Humidity20 ~ 95% RH non-condensing
  • Storage Temperature & Humidity-40 ~ +80℃; 10 ~ 95% RH
  • Temp. Coefficient±0.03%/℃ (0 ~ 60℃)
  • Vibration10 ~ 500Hz, 5G 12min./1cycle, 72min. total (X, Y, Z axes)
  • MTBF2300.1K hrs min. (Telcordia SR-332); 200.7K hrs min. (MIL-HDBK-217F, 25℃)
  • Dimension199 x 63 x 35.5 mm (L x W x H)
  • Weight0.85Kg
  • Packing16 pcs / 14.2Kg / 0.75CUFT
  • CertificationsUL8750 (Type HL), CSA C22.2 No. 250.13-12, ENEC, EN61347-1, EN61347-2-13, EN62384, GB19510.1/.14, IS15885(Part2/Sec13), EAC TP TC 004, KC, J61347, IP67 approved
  • EMC EmissionEN55015 (CISPR15), EN61000-3-2, EN61000-3-3, GB/T 17743
  • EMC ImmunityEN61000-4-2 to 4-6, 4-8, 4-11; EN61547
  • Dimming Function3-in-1 (0~10VDC, 10V PWM, resistance; via DIM+ and DIM-)
  • Max. No. of PSUs on 16A Circuit Breaker3 units (Type B) / 6 units (Type C) at 230VAC
  • Features200W constant power LED driver, universal AC input, IP67 metal case, built-in 3-in-1 dimming, surge protection (6KV/4KV), low standby power, >50,000 hrs life, 5-year warranty
MWXLG20012A
